FireTuff Private Limited is committed to safeguarding lives, property, and the environment by offering advanced firefighting equipment and solutions.
FireTuff Private Limited is committed to safeguarding lives, property, and the environment by offering advanced firefighting equipment and solutions.
| Category | Details |
|---|---|
| Manufacturer | M/s Firetuff Private Limited |
| Trade Mark | FIRETUFF |
| Standard Code | IS 15683:2018 |
| Type | Portable Stored Pressure |
| Extinguishing Medium | Clean Agent |
| Body | Mild Steel Sheet having Max. of 0.25% C, 0.05% P and 0.05% |
| Neck Ring | M.S. Pipe |
| Valve | Brass |
| Siphon Tube | Plastic |
| Pressure Gauge/Indicator | As per IS 15683:2018 |
| Wall Mounting Bracket with Screw | Mild Steel (Powder Coated) |
| Discharge with Nozzle | Hose Pipe |
| Performance Requirement | A) Min. effective Discharge Time: 13 Sec. (Actual: 15 Sec. approx) B) Bulk Range of Discharge: Min. 2 meter (Actual: 2.5 meter approx) C) Percentage of Discharge: Not Less than 85% (Actual: 94% approx) |
| Fire Rating | 3A, 89B |
| Temperature Range | -20C to 60C |
| Service Pressure | 15 bar |
| Maximum Service Pressure | 18 bar |
| Routine Tests | Pressure Test (Pt): 35 bar (3.5 MPa) Minimum Burst Pressure Test (Pb): 55 bar (5.5 MPa) Leakage Test: Water Dip Test |
| Type Tests | As per IS 15683 |
| Dimensions | Diameter: 1505 mm Height: 500 mm (Approx.) |
| Full Weight of Cylinder | 8.50 kg (Approx) |
| Anti-Corrosive Treatment | Phosphate Treatment followed by epoxy powder coating of body DFT not less than 60 |
| Accessories (Brackets & Screws) | Provided |
| Miscellaneous | Inspection & Testing: As per approved GTP Marking: As per IS 15683:2018 Approvals: BIS Maintenance, Care, and Refilling: As per IS:2190 |
| Packing | Corrugated Boxes |
