FireTuff Private Limited is committed to safeguarding lives, property, and the environment by offering advanced firefighting equipment and solutions.
FireTuff Private Limited is committed to safeguarding lives, property, and the environment by offering advanced firefighting equipment and solutions.
₹3,500.00\- (Inclusive of all taxes)
₹3,800.00\-
| Category | Details |
|---|---|
| Manufacturer | M/s Firetuff Private Limited |
| Trade Mark | �FIRETUFF� |
| Standard Code | IS 15683:2018 |
| Type | Portable Stored Pressure |
| Extinguishing Medium | Mono Ammonium Phosphate based dry powder |
| Body | Mild Steel Sheet having Max. of 0.25% C, 0.05% P and 0.05% |
| Neck Ring | M.S. Pipe |
| Valve | Brass chrome plated |
| Pressure Gauge/Indicator | As per IS 15683:2018 |
| Wall/Ceiling Mounting Bracket | Mild steel (Powder Coated) |
| Activation Temperature | 68 Degree |
| Performance Requirement | A) Min. effective Discharge Time: 6 Sec. (Actual: 8 Sec. approx.) B) Percentage of Discharge: Not Less than 85% (Actual: 94% approx) |
| Temperature Range | -20 �C to 60 �C |
| Service Pressure | 15 bar |
| Maximum Service Pressure | 18 bar |
| Routine Tests | Pressure Test (Pt): 35 bar (3.5 MPa) Minimum Burst Pressure Test (Pb): 55 bar (5.5 MPa) Leakage Test: Water Dip Test |
| Type Tests | As per IS 15683 |
| Dimensions | Diameter: 225�5 mm |
| Full Weight of Cylinder | 5 kg (Approx) |
| Anti-Corrosive Treatment | Phosphate Treatment followed by epoxy powder coating of body DFT not less than 50� |
| Accessories (Brackets & Screws) | Provided |
| Miscellaneous | Inspection & Testing: As per approved GTP Marking: As per IS 15683:2018 Approvals: BIS Maintenance, Care and Refilling: As per IS:2190 |
| Packing | Corrugated Boxes |
