₹29,500.00\- (Inclusive of all taxes)
₹32,500.00\-
| Category | Details |
|---|---|
| Manufacturer | M/s Firetuff Private Limited |
| Trade Mark | �FIRETUFF� |
| Standard Code | IS 16018 |
| Type | Stored Pressure |
| Extinguishing Medium | Mono Ammonium Phosphate based dry powder |
| Body | Mild Steel Sheet having Max. of 0.25% C, 0.05% P and 0.05% |
| Neck Ring | M.S. Pipe |
| Valve | Brass |
| Pressure Gauge/Indicator | As per IS 16018 |
| Wall Mounting Bracket with Screw | Mild Steel (Powder Coated) |
| Discharge with Nozzle | Hose Pipe |
| Performance Requirement | A) Min. effective Discharge Time: 30 Sec. (Actual: 32 Sec. approx) B) Bulk Range of Discharge: Min. 6 meter (Actual: 6.5 meter approx) C) Percentage of Discharge: Not Less than 85% (Actual: 94% approx) |
| Fire Rating | 20A, 233B |
| Temperature Range | -30 �C to 60 �C |
| Service Pressure | 15 bar |
| Maximum Service Pressure | 18 bar |
| Routine Tests | Pressure Test (Pt): 35 bar (3.5 MPa) Minimum Burst Pressure Test (Pb) for Body: 55 bar (5.5 MPa) Leakage Test: Water Dip Test |
| Type Tests | As per IS 16018 |
| Dimensions | Diameter: 300 mm (Approx.) Height: 980 mm (Approx.) |
| Full Weight of Cylinder | 50 kg (Approx) |
| Anti-Corrosive Treatment | Phosphate Treatment followed by epoxy powder coating of body DFT not less than 60� |
| Accessories (Brackets & Screws) | Provided |
| Miscellaneous | Inspection & Testing: As per approved GTP Marking: As per IS 16018 Approvals: BIS |
| Packing | Corrugated Boxes |
