FireTuff Private Limited is committed to safeguarding lives, property, and the environment by offering advanced firefighting equipment and solutions.
FireTuff Private Limited is committed to safeguarding lives, property, and the environment by offering advanced firefighting equipment and solutions.
₹25,500.00\- (Inclusive of all taxes)
₹26,500.00\-
| Category | Details |
|---|---|
| Manufacturer | M/s Firetuff Private Limited |
| Trade Mark | �FIRETUFF� |
| Standard Code | IS 16018 |
| Type | Trolley Mounted |
| Extinguishing Medium | AFFF (Aqueous Film Forming Foam) |
| Body | Mild Steel Sheet having Max. of 0.25% C, 0.05% P and 0.05% |
| Neck Ring | M.S. Pipe |
| Valve | Brass Chrome Plated |
| Pressure Gauge/Indicator | As per IS 16018 |
| Wall Mounting Bracket with Screw | Mild Steel (Powder Coated) |
| Discharge with Nozzle | Hose Pipe with Nozzle |
| Performance Requirement | A) Min. effective Discharge Time: 130 Sec. (Actual: 32 Sec. approx.) B) Bulk Range of Discharge: Min. 6 meter (Actual: 6.5 meter approx.) C) Percentage of Discharge: Not Less than 85% (Actual: 94% approx.) |
| Fire Rating | AIIIBC |
| Temperature Range | -30 �C to 60 �C |
| Service Pressure | 15 bar |
| Maximum Service Pressure | 18 bar |
| Routine Tests | Pressure Test (Pt): 35 bar (3.5 MPa) Minimum Burst Pressure Test (Pb): 55 bar (5.5 MPa) Leakage Test: Water Dip Test |
| Type Tests | As per IS 16018 |
| Dimensions | Diameter: 300 mm (Approx.) Height: 1200 mm (Approx.) |
| Full Weight of Cylinder | 84 kg (Approx.) |
| Anti-Corrosive Treatment | Phosphate Treatment followed by epoxy powder coating of body DFT not less than 60� |
| Accessories (Brackets & Screws) | Provided |
| Miscellaneous | Inspection & Testing: As per approved GTP Marking: As per IS 16018 Approvals: BIS |
| Packing | Corrugated Boxes |
